Two Series. One Brand.

Built For
Every Fleet.

The ALT Series covers applications that need data, configuration, and environmental hardening — diagnostic firmware, TREKon connectivity, and IP67 sealing. The LIT Series covers applications that need reliable charging without the connected layer — standard-duty, fixed-function, built to the same field demand.

One Question Decides The Series

Need charge data, diagnostics, and configurable output? Choose ALT. Need reliable charging without the connected layer? Choose LIT. Both ranges are built to what the field actually demands.

ALT Series · Engineered To Earn Its Place

Built from field demand,
for operators who push equipment.

Configurable voltage and current. Temperature-compensated charging that protects battery life. Onboard diagnostics that tell you what the charger sees. Sealed to IP67 against dust, water and vibration, and rated from −30°C to 65°C. When a job needs visibility, configurability, or hardware that survives punishment, ALT is specified for it.

1 / 9
01 · Compact

ALT-400

408W · 24V · 17A

The compact entry to the ALT range. Specified for portable equipment, single-machine fleets and OEMs that need a 24V solution without third-party tooling.

Output Power408 W
Voltage24 V
Charge Current17 A
ChemistryLead-Acid · Lithium
Ingress RatingIP67
DiagnosticsTREKon Bluetooth
ComplianceUL1236, FCC, IEC61000
Operating Range−30°C to 65°C
Dimensions208 × 152 × 80 mm
Weight2.1 kg
ALT-400 Datasheet
1 / 9
02 · Mid-Range

ALT-700 (700S)

720W · 24V or 48V

The 720W workhorse. ALT-700 runs 24V at 30A. The 700S variant carries the same chassis at 48V / 15A. Sized for single-shift floor care and small motive fleets.

Output Power720 W
Voltage24V (700) · 48V (700S)
Charge Current30A (700) · 15A (700S)
ChemistryLead-Acid · Lithium
Ingress RatingIP67
DiagnosticsTREKon Bluetooth
ComplianceUL1236, FCC, IEC61000
Operating Range−30°C to 65°C
Dimensions208 × 152 × 80 mm
Weight2.3 kg
ALT-700 Datasheet ALT-700S Datasheet
1 / 9
03 · Heavy Mid-Range

ALT-900 (900S)

864W · 24V or 48V

The double-shift charger. ALT-900 at 24V / 36A or the 900S at 48V / 18A. Used in larger floor care equipment and mid-size motive applications.

Output Power864 W
Voltage24V (900) · 48V (900S)
Charge Current36A (900) · 18A (900S)
ChemistryLead-Acid · Lithium
Ingress RatingIP67
DiagnosticsTREKon Bluetooth
ComplianceUL1236, FCC, IEC61000
Operating Range−30°C to 65°C
Dimensions203.5 × 186 × 138 mm
Weight4.1 kg
ALT-900 Datasheet ALT-900S Datasheet
1 / 9
04 · High Output

ALT-1700 / 1700RC

1680W · 48V · 35A

Sized for MEWP and golf duty cycles. The 1700RC comes with Battery Reconditioning to revive discharged batteries.

Output Power1680 W
Voltage48 V
Charge Current35 A
ChemistryLead-Acid · Lithium
Ingress RatingIP67
DiagnosticsTREKon Bluetooth
ComplianceUL1236, FCC, IEC61000
Operating Range−30°C to 65°C
Dimensions203.5 × 186 × 138 mm
Weight4.1 kg
ALT-1700 Datasheet ALT-1700RC Datasheet
1 / 9
05 · Flagship

ALT-3000

2880W · 48V · 60A

The largest charger in the line. Specified for the biggest MEWP, AGV and industrial EV applications where charge time matters.

Output Power2880 W
Voltage48 V
Charge Current60 A
ChemistryLead-Acid · Lithium
Ingress RatingIP67
DiagnosticsTREKon Bluetooth
ComplianceUL1236, FCC, IEC61000
Operating Range−30°C to 65°C
Dimensions359 × 238 × 100 mm
Weight6.8 kg
ALT-3000 Datasheet
MEWP scissor lift application
01 · Application

MEWP

Scissor lifts, boom lifts and AWP fleets. The ALT-1700 sits at the centre of this category, with the ALT-3000 reserved for the largest platforms. TREKon telemetry tracks charge cycles across rental fleets.

Scissor Lifts Boom Lifts AWP
Recommended: ALT-1700
Ride-on floor scrubber in commercial environment
02 · Application

Floor Care

Scrubbers, sweepers and burnishers. ALT-700 / 900 or LIT-600 / 720 cover this category depending on whether diagnostic firmware is required. Lead-acid and lithium variants supported through the same chassis.

Walk-Behind Scrubbers Ride-On Sweepers Burnishers
Recommended: ALT-700 / 900
Industrial autonomous robot
03 · Application

Industrial EV

Utility vehicles, burden carriers, AGV. ALT-1700 and ALT-3000 deliver the duty cycle these platforms need. Remote-controlled charge initiation available on the 1700RC.

Utility Vehicles Burden Carriers AGV
Recommended: ALT-1700 / 3000
Forklift in warehouse
04 · Application

Golf & Material Handling

Golf carts, pallet trucks and forklifts. ALT-700 / 900 or LIT-900 / 1200 cover the smaller end. ALT-1700 picks up the heavier carts and pallet trucks.

Golf Carts Pallet Trucks Class III Forklifts
Recommended: ALT-700 to 1700
Documents

Specifications.
Manuals. Brochures.

All datasheets and product documentation for the ALT and LIT ranges. Download what you need.

Product Brochure

Overview of the full ALT range, key specs, and applications. Best for first-time enquiries and OEM evaluations.

Download

Charger User Manual

Installation, wiring, charge profiles and field troubleshooting for the full ALT range.

Download

TREKon App Guide

Step-by-step setup for iOS and Android. Bluetooth pairing, profile selection, fleet diagnostics.

Download

Spec Comparison Sheet

Excel workbook with separate tabs for the ALT and LIT ranges. Compares power, voltage, current, chemistry, ingress, and compliance specs side-by-side.

Download

Need help sizing for your fleet?

Talk To Engineering
